3D Composite Drainage HDPE Geonet 300GSM in Landfill Network

Basic Info

Model NO.	300gsm
Transport Package	Each Roll Is Wrapped with a Woven Bag with Label
Specification	CE SGS
Trademark	HONGXIANG
Origin	Made in China
HS Code	3926909090
Production Capacity	50000m2week

Product Description

Tri-Dimension Composite Geonet for Drainage 1 for Road Railway Highway Tunnel
It is made of HDPE polymer by extruding into a tri-dimension structure net. Net shape.

Specification of Tri-Dimension Composite Geonet for Drainage 1 for Road Railway Highway Tunnel
Net thickness: 5mm - 8mm, width: 2m - 4m, length as request.

Property of Tri-Dimension Composite Geonet for Drainage 1 for Road Railway Highway Tunnel
I. High drainage property, can bear long time high pressu re
2. High tensile strength and shear strength
3. Reduce probability of geotextile penetration into net to keep high hydraulic conductivity

Application of Tri-Dimension Composite Geonet for Drainage 1 for Road Railway Highway Tunnel
Drainage in landfill, roadbed and road surface, railway, tunnel, underground, retaining wall back
Garden and playground.

Production standard of Tri-Dimension Composite Geonet for Drainage 1 for Road Railway Highway Tunnel
GB/T19470-2004

	item	Unit
			1200g	1400g	1600g	1800g	2000g
1	compound weight of unit area	g/m2	≥1200	≥1400	≥1600	≥1800	≥2000
2	compound thickness	mm	≥6.0	≥7.0	≥8.0	≥9.0	≥10.0
3	compound tensile strength	KN/m	≥16.0	≥16.0	≥16.0	≥16.0	≥16.0
4	compound hydraulic conductivity	m2/s	≥1.2×10-4	≥1.2×10-4	≥1.2×10-4	≥1.2×10-4	≥1.2×10-4
5	net and non-woven geotextile	KN/m	≥0.3	≥0.3	≥0.3	≥0.3	≥0.3
	Peel strength
6	net thickness	mm	≥5.0	≥5.0	≥6.0	≥7.0	≥8.0
7	net tensile strength	KN/m	≥13.0	≥15.0	≥15.0	≥15.0	≥15.0
8	non-woven geotextile weight of unit area	g/m2	≥200	≥200	≥200	≥200	≥200
9	non-woven geotextile permeability	cm/s	≥0.3	≥0.3	≥0.3	≥0.3	≥0.3
10	width	m	2.1	2.1	2.1	2.1	2.1
11	roll length	m	30	30	30	30	30

Area	Application of Geosynthetics
Hydraulic	Lagooning and Water Treatment, Ornamental Ponds, Golf Courses Aquaculture and Desalination Water LagoonsTanks, Reservoirs, Liquid WasteFloating Cover SolutionsDrainage and FiltrationShading Cover Solutions
Environment	Tailing ponds, Leach mining,Landfills,Landfill Capping,Protection against corrosion,Vertical Barriers
Civil Works	Erosion Control, Secondary Containment, Tunnels,Linear and Surface Works,Consolidation of Margins,Soil Reinforcement,Soil Separation.
Building	Parkings,Roofing,Soundproofing building
